Relay logic Control Panels

The Relay Logic control panel provides a reliable means of controlling one 120, 208, or 240V single phase pump in pump chambers, sump pump basins, irrigation systems and lift stations. A magnetic motor contractor is used to turn the pump on and off. If an alarm condition occurs, an alarm switch activates the audible/visual alarm system. Standard components are used for easy troubleshooting and service.

Features

• Controls one 120, 208, or 240V single phase pump
• Inner door for added safety
• NEMA 4X lockable enclosure rated for indoor/outdoor use
• Magnetic motor contactor turns the pump on/off
• Alarm test/normal/silence switch (exterior)
• HOA switch on inner door for manual pump control
• Relay logic provides pump control
• Pump run indicator light on inner door
• Circuit breakers provide pump disconnect, branch circuit protection, and control/alarm power disconnect
• Ground lugs
• Spare replacement control relay
• Float switch terminal block
• Input power terminal block
• Red alarm beacon and horn
• Horn silence relay
